3T Exploro RaceMax Rival AXS 2x Carbon Gravel Bike

The Exploro RaceMax Rival AXS 2x Carbon Gravel Bike by 3T - A gravel racing machine with electronic 2x shifting

The Exploro RaceMax gravel bike from 3T is made of carbon and is equipped with SRAM Rival AXS 2x components. The electronic drivetrain groupset with two chainrings provides you with a wide range of gear ratios. This allows you to ride fast on flat ground, but also to master steep inclines without any problems. The frame has an extra-wide down tube and an extremely narrow head tube. Together with the aero seatpost and a narrow fork crown, this results in a very aerodynamic bike. The wide steerer tube and the chainstays, which are lowered on both sides, provide sufficient stability. The Fulcrum Rapid Red 900 wheels are tubeless compatible, as are the Pirelli Cinturato tyres. With these you'll be fast on asphalt as well as unpaved roads. With this bike, the door to the gravel racing scene is wide open to you.

Information regarding the return of batteries and electrical equipment:

Information on the return and disposal of batteries and electrical equipment can be found here.

Specifications:

Application:

Gravel

Wheel Size:

28"

Sizes:

XS, S, M, L, XL

Frame Material:

Carbon

Fork Material:

Carbon

Components:

Frame:

Exploro RaceMax

Fork:

Fango RaceMax

Stem:

Apto Stealth

Handlebars:

Superergo Pro

Headset:

3T MinMax by CaneCreek IS42/28.6 - IS47/38

Seatpost:

Charlie Sqaero Team

Saddle:

Selle Italia Model X Superflow

Crank:

SRAM Rival AXS, 33.46 t

Pedals:

none

Brakes:

SRAM Rival AXS, Flat Mount, hydraulic, Center Lock Disc, 160 mm

Shift/Brake lever:

SRAM Rival AXS eTap

Rear Derailleur:

SRAM Rival AXS, long cage

Front Derailleur:

SRAM Rival AXS

Cassette:

12-speed Rival AXS, 10-36 t

Chain:

SRAM PC-1130

Wheels:

Fulcrum Rapid Red 900, Disc Brake, 700C, Tubeless Ready

Tyres:

Pirelli Cinturato M, 700C

Approved For:

Weight Limit:

110 kg (rider weight)

Rotor Size (max.):

160 mm

Features:

• gravel bike with SRAM Rival AXS electronic drivetrain and two chainrings
• narrow head tube like on road bikes with 1 1/4" steerer tubes
• large 1.5" steerer tube for more stability
• reduced fork crown for less weight and better aerodynamics
• integrated fender mounts
• self-aligning seatpost clamp

Geometry:

XS:

Manufacturer Designation:

51

Recommended Height:

153 - 167 cm

Stack:

542 mm

Reach:

366 mm

Seat Tube Length:

463 mm

Effective Top Tube Length:

526 mm

Chainstay Length:

415 mm

Wheelbase:

1008 mm

BB Drop:

79 mm

Seat Tube Angle:

74.0°

Head Tube Angle:

69.5°

Stem Length:

80 mm

Crank Arm Length:

170.0 mm

S:

Manufacturer Designation:

54

Recommended Height:

164 - 177 cm

Stack:

564 mm

Reach:

377 mm

Seat Tube Length:

490 mm

Effective Top Tube Length:

546 mm

Chainstay Length:

415 mm

Wheelbase:

1008 mm

BB Drop:

77 mm

Seat Tube Angle:

73.5°

Head Tube Angle:

71.0°

Stem Length:

90 mm

Crank Arm Length:

172.5 mm

M:

Manufacturer Designation:

56

Recommended Height:

175 - 185 cm

Stack:

584 mm

Reach:

385 mm

Seat Tube Length:

518 mm

Effective Top Tube Length:

566 mm

Chainstay Length:

415 mm

Wheelbase:

1014 mm

BB Drop:

77 mm

Seat Tube Angle:

73.0°

Head Tube Angle:

72.0°

Stem Length:

100 mm

Crank Arm Length:

172.5 mm

L:

Manufacturer Designation:

58

Recommended Height:

183 - 196 cm

Stack:

604 mm

Reach:

393 mm

Seat Tube Length:

545 mm

Effective Top Tube Length:

586 mm

Chainstay Length:

415 mm

Wheelbase:

1024

BB Drop:

75 mm

Seat Tube Angle:

72.5°

Head Tube Angle:

72.0°

Stem Length:

110 mm

Crank Arm Length:

175.0 mm

XL:

Manufacturer Designation:

61

Recommended Height:

from 192 cm

Stack:

632 mm

Reach:

404 mm

Seat Tube Length:

572 mm

Effective Top Tube Length:

606 mm

Chainstay Length:

415 mm

Wheelbase:

1044 mm

BB Drop:

72 mm

Seat Tube Angle:

72.5°

Head Tube Angle:

72.0°

Stem Length:

120 mm

Crank Arm Length:

175.0 mm

Technology:

Checkpoint Charlie
Optimising the length of the seat tube is just as important as every gram of weight on the strenuous climbs that you will ride on your Exploro. However, ensuring safety is significantly more important. If you want to shorten the tube, use the checkpoint on the seat tube to determine whether the minimum inner length has been reached.

Manufacturer Numbers:

XS:

9250AGDJ33W

S:

9250AGDK33W

M:

9250AGDL33W

L:

9250AGDM33W

XL:

9250AGDN33W

Shipping Notice:

The shipment is sent pre-assembled by a forwarding agent. The delivery time is extended by 2-5 days, depending on the overall volume of orders. For individual consultation, please contact our customer service team.

Contents:

• 1 x 3T Exploro RaceMax Rival AXS 2x Carbon gravel bike
