GALFER Disc Brake Adapter for 223 mm Brake Rotors

This GALFER disc brake adapter enables the use of a 223 mm diameter brake rotor with a suitable mount.

Guidelines for Replacing E-bike Components:

Before you replace components on your e-bike, please read through the guidelines for component replacement for CE-marked e-bikes/pedelecs with pedal assistance.

Technical Information:

Adapter Material:

aluminium

Bolt Material:

steel

Rotor Size:

223 mm

Models:

PM 8" to PM +20 mm

Fork Mount:

post mount 8"

Caliper Mount:

post mount

Increased Height:

20 mm

Manufacturer Number:

SB002

PM 7" to PM +43 mm

Frame Mount:

post mount 7"

Fork Mount:

post mount 7"

Caliper Mount:

post mount

Increased Height:

43 mm

Manufacturer Number:

SB001

PM 6" to PM +63 mm

Frame Mount:

post mount 6"

Fork Mount:

post mount 6"

Caliper Mount:

post mount

Increased Height:

63 mm

Manufacturer Number:

SB003

Fox 40 / 49 to PM +20 mm

Fork Mount:

post mount 8"

Caliper Mount:

post mount

Increased Height:

20 mm

Compatibility:

Fox Racing Shox 40, Fox Racing Shox 49

Manufacturer Number:

SB005

Contents:

• 1 x GALFER disc brake adapter
• 2 x bolts
• 2 x washers (only PM 6" to PM +63 mm) or 4 x washers
