Schwalbe Racing Ray Evolution ADDIX SpeedGrip Super Ground 29" Folding Tyre

The Schwalbe Racing Ray Evolution ADDIX SpeedGrip Super Ground 29" folding tyre - the specialist for the front wheel

The Racing Ray Evolution 29" folding tyre is designed to be a congenial partner for Racing Ralph. Schwalbe has given the tyre for the front wheel staggered central and stable shoulder lugs. Combined with the aggressive tread pattern reliable steering behaviour, precise cornering even at the limits and strong braking performance are achieved.
Racing Ray comes with the ADDIX SpeedGrip compound and Super Ground carcass.

Guidelines for replacing E-bike components:

Before you replace components on your e-bike, please read through the guidelines for component replacement for CE-marked e-bikes/pedelecs with pedal assistance.

Specifications:

Application:

Cross Country, All Mountain

Product Line:

Evolution

Type:

folding tyre

Tubeless System:

TL Easy

Technical Information:

Rubber Compound:

ADDIX Speedgrip

Tread:

HS 489

Carcass:

67 tpi

Sidewall:

SnakeSkin

Models:

29x2.10:

Dimensions:

29 x 2.10"

ETRTO:

54-622

Air Pressure:

2 - 4 bar

Load Capacity (max.):

110 kg

Manufacturer Number:

11601130.01

29x2.25:

Dimensions:

29 x 2.25"

ETRTO:

57-622

Air Pressure:

1.8 - 3.7 bar

Load Capacity (max.):

120 kg

Manufacturer Number:

11601100.01

29x2.35:

Dimensions:

29 x 2.35"

ETRTO:

60-622

Air Pressure:

1.6 - 3.5 bar

Load Capacity (max.):

125 kg

Manufacturer Number:

11654028.01

Note:
The load capacity shown refers to only one tyre. To check whether the tyre is suitable for your total weight (rider + bike), this value can be doubled, as the weight is then distributed over two tyres.

Technology:

Evolution
The best that can be done. High quality materials. The latest technology.

ADDIX Speedgrip
The balance between speed, grip and durability make the ADDIX SpeedGrip a universal compound, perfectly suited for Cross Country and All Mountain.

Super Ground
The Super Ground carcass is suitable for hardtails and bikes with medium suspension travel, for Cross Country and All Mountain. SnakeSkin protects the entire construction.
Tyres with Super Ground carcass are Tubeless Easy.

E-25
For normal pedelecs with pedal assistance up to 25 km/h, the law does not prescribe any special tyres. With these bikes, however, loads and average speeds are usually higher than with normal bikes, so Schwalbe recommends only certain tyres as " E-Bike Ready 25" and provides them with a special label.

Contents:

• 1 x Schwalbe Racing Ray Evolution ADDIX SpeedGrip Super Ground 29" folding tyre
