Shimano Deore FC-M6000-2 10-speed Chainring

The Shimano Deore 10-speed Chainring for the FC-M6000-2 crank

This Shimano chainring is compatible with the Deore FC-M6000 2x10-speed crank. Three combinations can thus be formed: 24-34, 26-36 and 28-38. The chainrings are also suitable for the FC-M6000 with a chainline that is 3 mm further out.

Specifications:

Application:

All Mountain, Cross Country

Mount:

96/64 mm bolt circle diameter, 4-arm asymmetrical

Teeth:

24 t, 26 t, 28 t, 34 t, 36 t, 38 t

Gearing:

2x10-speed

Technical Information:

Combinations:

24-34 t, 26-36 t, 28-38 t

Material:

steel (24 T to 28 T), aluminium/fibreglass composite (34 T to 38 T)

Compatibility:

• Deore FC-M6000-2
• Deore FC-M6000-B2
• 26 T also compatible with the FC-M4100-(B)2

Features:

• large chainring anodised, small chainring painted

Models:

24 tooth:

Type:

BE

Bolt Circle Diameter:

64 mm

Manufacturer Number:

Y-1WD24000

26 tooth:

Type:

BF

Bolt Circle Diameter:

64 mm

Manufacturer Number:

Y-1WD26000

28 tooth:

Type:

BG

Bolt Circle Diameter:

64 mm

Manufacturer Number:

Y-1WD28000

34 tooth:

Type:

BE

Bolt Circle Diameter:

96 mm

Manufacturer Number:

Y-1WD98040

36 tooth:

Type:

BF

Bolt Circle Diameter:

96 mm

Manufacturer Number:

Y-1WB98010

38 tooth:

Type:

BG

Bolt Circle Diameter:

96 mm

Manufacturer Number:

Y-1WD98030

Note to Type Designation:

The type designation (one or two characters) helps identify the compatibility of various chainrings with other chainrings. Because the larger chainrings have specially-formed teeth and upward shifting assistance, only particular smaller chainrings will match to ensure proper shifting performance. An XY chainring should only be combined with another XY chainring. This applies to all other types as well.

Contents:

• 1 x Shimano Deore M6000 chainring
