Shimano XT FC-T8000 10-speed Chainring for Chain Guards

Shimano XT 10-speed Chainring for the FC-T8000 Crank

This Shimano 10-speed chainring for the XT FC-T8000 touring crank is prepared for the use of a chain guard ring. It has 48 teeth, a bolt circle diameter of 104 mm and is made of aluminium.

Specifications:

Application:

City & Touring

Attachment:

104 mm bolt circle diameter, 4-arm

Teeth:

48 t

Gearing:

3x10-speed

Technical Information:

Combinations:

26-36-48 t with chain guard

Material:

Aluminium

Compatibility:

• XT FC-T8000

Features:

• anodised
• designed for chain guards

Models:

48 tooth:

Type:

AL

Manufacturer Number:

Y-1VL98010

Note:

The 36 tooth chainring (Y-1MP98020) is identical to XT FC-M780 chainring. The 26 tooth chainring (Y-1J226000) is identical to XT FC-M771-K chainring.

Note to Type Designation:

The type designation (one or two characters) helps identify the compatibility of various chainrings with other chainrings. Because the larger chainrings have specially-formed teeth and upward shifting assistance, only particular smaller chainrings will match to ensure proper shifting performance. An XY chainring should only be combined with another XY chainring. This applies to all other types as well.

Contents:

• 1 x Shimano XT FC-T8000 chainring for chain guards
