Specialized Mountain bike - satin metallic spruce-purple haze/M/180 mm/44 mm/165,0 mm/29" (front), 27.5" (rear)

Specialized Mountain bike

Item number: 96601

Designed for the thrill-seekers and downhill enthusiasts, the Specialized Status 2 170 DH 29" / 27,5" Mountainbike combines high-end components and innovative design to deliver unparalleled performance on the most challenging terrains. At its core, the bike features a robust Specialized M5 aluminum frame, paired with a Four-Bar Linkage kinematics system that ensures responsive handling and optimal suspension performance. The SRAM PC-1110 chain and GX DH 7-speed derailleur provide smooth and reliable shifting, while the SRAM DUB Threaded BSA Wide bottom bracket offers exceptional durability and stability. The bike rolls on Specialized Roval rims, tubeless-ready and 28 mm wide, matched with Specialized Butcher Grid Gravity T9 tires (29 x 2.30" front and 27.5 x 2.30" rear) to deliver superior grip and control on any surface. Hydraulic SRAM Maven Bronze disc brakes ensure powerful and precise stopping power, giving you confidence on steep descents. The DT Swiss Industry spokes and Specialized hubs (20 x 110 mm front and 12 x 148 mm rear thru-axle) guarantee robustness and smooth wheel performance. Comfort isn't overlooked, thanks to the Specialized Body Geometry Henge DH saddle and Deity Lockjaw grips, which provide support and control during aggressive rides. The SRAM Descendant DH crankset, with its 165.0 mm length and 34T, is designed to handle the rigors of downhill racing, ensuring that every pedal stroke translates into speed. Whether you're tackling technical descents or pushing your limits on the trails, this bike is equipped to handle it all, ensuring every ride is an adrenaline-fueled adventure.

Specifications:

Application:
Downhill, MTB
Brake Type:
disc
Rear triangle material:
Aluminium
Kinematics:
Four-Bar Linkage
Frame material:
Aluminum
Gender:
Women's, Men´s

Technical Information:

:
34,9 mm

Components:

Brakes:
SRAM Maven Bronze, hydraulic
Rear Wheel Tyre:
Specialized Butcher Grid Gravity T9, 27,5 x 2,30"
Rims:
Specialized Roval, Tubeless Ready, Rim width: 28 mm
Grips:
Deity Lockjaw
Rear Hub:
Specialized, 12 x 148 mm, Thru Axle
Bottom Bracket:
SRAM DUB Threaded BSA Wide
Chain:
SRAM PC-1110
Cassette:
SRAM GX DH, 11-24 Z, 7-speed
Front Wheel Tyre:
Specialized Butcher Grid Gravity T9, 29 x 2,30"
Pedals:
without
Remote System:
without
Saddle:
Specialized Body Geometry Henge DH
Seatpost:
Specialized, Setback: 5 mm
Shift Lever:
SRAM GX DH
Derailleur:
SRAM GX DH, 7-speed
Spokes:
DT Swiss Industry
Crankset:
SRAM Descendant DH, 165,0 mm, 34 T
Frame:
Specialized M5
Front Derailleur:
without
Front Hub:
Specialized, 20 x 110 mm

Approved For:

Weight Limit:
  • 136 kg
  • System

Features:

- High-performance MTB designed for downhill enthusiasts, featuring a robust Specialized M5 aluminum frame and Four-Bar Linkage kinematics for superior handling. - Equipped with SRAM GX DH 7-speed drivetrain, including a SRAM PC-1110 chain and SRAM DUB Threaded BSA Wide bottom bracket, ensuring precise and reliable shifting. - Hydraulic SRAM Maven Bronze disc brakes provide powerful and responsive stopping power in all conditions. - Specialized Roval tubeless-ready rims with a 28 mm width, paired with Specialized Butcher Grid Gravity T9 tires (29 x 2.30" front, 27.5 x 2.30" rear), offer excellent traction and control. - The bike features Deity Lockjaw grips and a Specialized Body Geometry Henge DH saddle with a width of 130 mm for comfort and control during aggressive riding. - DT Swiss Industry spokes, Specialized front hub (20 x 110 mm), and rear hub (12 x 148 mm, Thru Axle) ensure durability and reliable performance on the toughest trails.

Geometry:

satin metallic spruce-purple haze/S/180 mm/44 mm/165,0 mm/29" (front), 27.5" (rear):
Recommended Rider Height:
157 - 173 cm
Geo based on Fork Length:
581 mm
Seat Tube Length:
400 mm
Head Tube Length:
100 mm
Bottom Bracket Height:
350 mm
BB Drop:
26 mm,34 mm
Chainstay Length:
428 mm,432 mm
Head Tube Angle:
64 ,63.5
Standover Height:
735 mm
Wheelbase:
1221 mm
Reach:
451 mm,445 mm
Stack:
620 mm,625 mm
Seat Tube Angle:
77.6 ,77
Effective Top Tube Length:
595 mm
satin metallic spruce-purple haze/M/180 mm/44 mm/165,0 mm/29" (front), 27.5" (rear):
Recommended Rider Height:
165 - 180 cm
Geo based on Fork Length:
581 mm
Chainstay Length:
428 mm,432 mm
Seat Tube Length:
420 mm
Head Tube Length:
110 mm
Bottom Bracket Height:
350 mm
BB Drop:
26 mm,34 mm
Head Tube Angle:
64 ,63.5
Reach:
476 mm,470 mm
Wheelbase:
1250 mm
Seat Tube Angle:
77.6 ,77
Stack:
629 mm,634 mm
Standover Height:
742 mm
Effective Top Tube Length:
635 mm
satin metallic spruce-purple haze/L/180 mm/44 mm/165,0 mm/29" (front), 27.5" (rear):
Recommended Rider Height:
173 - 188 cm
Geo based on Fork Length:
581 mm
Seat Tube Length:
440 mm
Head Tube Length:
120 mm
Bottom Bracket Height:
350 mm
BB Drop:
26 mm,34 mm
Chainstay Length:
428 mm,432 mm
Head Tube Angle:
64 ,63.5
Reach:
501 mm,495 mm
Standover Height:
748 mm
Wheelbase:
1285 mm
Stack:
638 mm,643 mm
Seat Tube Angle:
77.6 ,77
Effective Top Tube Length:
676 mm

Manufacturer Number:

  • satin metallic spruce-purple haze/S/180 mm/44 mm/165,0 mm/29" (front), 27.5" (rear): 93724-7002
  • satin metallic spruce-purple haze/M/180 mm/44 mm/165,0 mm/29" (front), 27.5" (rear): 93724-7003
  • satin metallic spruce-purple haze/L/180 mm/44 mm/165,0 mm/29" (front), 27.5" (rear): 93724-7004

Shipping Notice:

The shipment is sent pre-assembled by a forwarding agent.
The delivery time is, depending on the workshop workload, 2 - 5 days in addition to the delivery time shown in the online shop.
For individual consultation, please contact our customer service team.

Contents:

- 1 x Specialized Status 2 170 DH 29" / 27.5" mountain bike

Weight:

  • satin metallic spruce-purple haze/M/180 mm/44 mm/165,0 mm/29" (front), 27.5" (rear): 17.18 kg

Manufacturer:

Specialized Germany GmbH
Hauptstraße 4
83607 Föching
Germany
www.specialized.com/contact-us
